Grist Cases & Grain Handling Equipment

What is a Grist Case?

A grist case is a cracked grain storage vessel, and is a key component in beer brewing. Positioned between the grain mill and the brewhouse, the grist case is the intermediary stop for grain after cracking, prior to introduction into the brew kettle. The grist case is one component of the brewery grain handling system which also includes the grain auger, grain mill, and grist hydrator.

Why Select a PKW Grist Case?

PKW Grist Case 3D

Portland Kettle Works’ grist cases provide the brewer with several key advantages:

  • Greatly reduces the inherent possibility of equipment failure in the brewery grain delivery system which can cause costly delays or short batching
  • Field tested by some of America’s leading craft brewers
  • Capacities from 200 pounds (91kg) to 4000 pounds (1815 kg)
  • Integrates seamlessly into the grain auger boot
  • When properly installed in combination with the MaltMaster grain mill and the PKW grain auger system, the grist case greatly reduces grain dust
  • Allows the brewer to crack grains immediately before brew to ensure freshness
  • Provides long-term cost savings over more expensive pre-cracked grain
  • Eliminates labor as a single person can manage dough-in to the brewhouse
Get a Quote Ask a Question

PKW Grist Case Specifications

PKW MaltMaster Grain Mill & Handling System Cover

PKW MaltMaster Grain Mill & Handling System Brochure

Download Document
PKW Grain Handling System Floor Mount Spec Image

PKW Grain Handling System Floor-Mount Spec Sheet

Download Document
PKW Grain Handling System Suspended Mount Spec Image

PKW Grain Handling System Suspended-Mount Spec Image

Download Document

As with all our brewing equipment, Portland Kettle Works grist cases are designed and manufactured to exacting standards.

  • Capacities available include:
    • bbl: 2, 3.5, 5, 7, 10, 15, 20, and 30
    • hL: 2.3, 4.1, 5.9, 8.2, 11.7, 17.6, 23.5, and 35.2
    • Other capacities available upon request
  • 100% 304 food-grade stainless steel
  • Floor or suspended mounting included
  • Equipped with quick-connect drop-out chute for direct connection of the grain auger assembly
  • Allows for addition of an optional grist hydrator which virtually eliminates dough balls. The hydrator collar attaches between the grist case and mash tun to assure a thorough wetting of the grist on the way into the mash tun. This attachment raises your brewhouse efficiency, produces a more consistent mash profile, and eases strain on the brew crew.
